PARSIFAL 500/500
Continuous through feed grinder equipped with 2 opposite vertical spindles and 2 opposite planetary brushing units
Performances
Resolution 0.001 mm
High performance spindles, direct drive
Modular rigid frame of grey cast iron combined with prestressed concrete
Measurement and automatic servo
Additional brushing module
Automatic or semi-automatic
Technical specifications
|
Number of spindles Spindle Z-Axis Rotation speed Power Width max. Height max. Abrasive tools Grinding wheel Infeed Electrical control Total weight Stock removal Resolution |
2+2 brushing ø200×500 mm 2×120 mm 0 – 4500 rpm 2×20 +2×7 kW 10 mm 20 mm CBN/diamond/Al2O3 ø400 mm 0-4000 mm/min Siemens S7/1500/TIA 6 t 1 mm 0,001 mm |
